Mainly Technology Parameter :
1.:Single Core Machine Box for single passage direction Double Core Machine Box for multi-passage direction
2. Passage extent£º¡Ü700(mm)
3. Appearance Sizes£º1600*350*1100mm
4. Power Voltage: AC220¡À10V£¬50HZ
5.Working Environment: 15centigrade¡«60centigrade(indoor)
6.Relative humidity: ¡Ü90%
7.Input port:
a. more than 10ms 12V impulse signal
b. Drive electrical current: more than 10mA£»
8.Communication port: :RS485
9.Communication distance: 1200m
10.Transit Speed: 50 person/minute
11.Opening /Shutting down time:1 second
